As industrial facilities adopt connected equipment, Industrial Ethernet, Time-Sensitive Networking (TSN), edge computing and more advanced network architectures are becoming increasingly relevant. However, selecting new technology alone does not guarantee better performance. The network must be designed around the actual requirements of the production process.
This guide explains nine practical checks for improving industrial networking, identifying communication problems and planning reliable upgrades for PLC and SCADA environments.
Quick Answer: Improving industrial networking requires mapping connected devices, measuring communication performance, confirming protocol compatibility, strengthening OT cybersecurity, evaluating network redundancy and testing recovery procedures. Facilities should prioritize reliable local control communication before introducing additional connectivity, analytics or remote services.
1. Map Industrial Devices and Communication Requirements
The first step toward improving industrial networking is understanding how equipment communicates across the facility. An industrial network may connect PLCs, HMIs, variable frequency drives, remote I/O modules, engineering workstations, SCADA servers and industrial sensors.
These devices have different communication requirements. Some exchange control information continuously, while others transmit monitoring data or operational reports. Treating every connection as identical can create unnecessary network traffic and complicate troubleshooting.
Identify Connected Industrial Equipment
Begin by documenting the devices connected to the production network. The inventory should include:
- PLC models, firmware versions and network interfaces.
- HMI devices and operator workstations.
- Industrial Ethernet switches and network gateways.
- Variable frequency drives and remote I/O modules.
- SCADA servers and engineering workstations.
- Industrial sensors and connected monitoring equipment.
- External connections used for approved remote access.
Document Communication Paths
Identify which devices exchange information, the protocols involved and the purpose of each connection. Document the required communication paths between controllers, supervisory applications and supporting systems.
Separate local control dependencies from monitoring, reporting and external connectivity. This distinction helps establish which functions must remain available if a server, external connection or supervisory application becomes unavailable.
Establish Network Ownership and Operational Requirements
Network documentation should also identify who is responsible for controllers, switches, applications and third-party equipment. Record production schedules, maintenance windows and vendor restrictions before planning changes.
For a broader understanding of how industrial controllers and supervisory systems work together, explore Smartopia’s industrial automation systems guide.
2. Measure Network Performance and Identify Communication Problems
Network performance problems can appear as delayed equipment responses, communication timeouts, disconnected devices, outdated HMI values or interruptions in SCADA data collection.
Replacing network equipment without identifying the underlying problem can introduce unnecessary costs without correcting the original issue. A better approach is to establish a performance baseline and compare network observations with controller, HMI and SCADA event records.
Important Industrial Network Performance Indicators
| Performance Indicator | What It Helps Identify |
|---|---|
| Latency | Communication delay between connected devices. |
| Jitter | Variation in communication delay affecting timing-sensitive applications. |
| Packet Loss | Lost network packets that may interrupt communication. |
| Network Utilization | Traffic levels and potential congestion. |
| Interface Errors | Possible cabling, connector, port or configuration problems. |
| Connection Availability | Recurring link changes, device disconnects and communication interruptions. |
| Application Timeouts | Communication problems affecting PLC, HMI or SCADA applications. |
Identify the Source of Network Delays
When communication problems occur, investigate whether they originate from physical infrastructure, switching configuration, protocol compatibility, endpoint performance or application settings.
For example, an outdated HMI value may result from a communication timeout rather than insufficient internet bandwidth. Similarly, packet loss between a controller and a remote I/O device requires investigation within the local industrial network.
There is no universal latency or utilization threshold suitable for every industrial application. Performance requirements should be established using the relevant equipment specifications and application needs.
For additional technical context, consult Cisco’s Industrial Automation Design Guide.
3. Industrial Ethernet, Protocol Compatibility and Time-Sensitive Networking
Industrial Ethernet provides the communication foundation for many modern automation environments. It connects controllers, drives, sensors, operator interfaces and supervisory applications through a common physical networking infrastructure.
However, connecting equipment through Ethernet does not automatically guarantee protocol compatibility, predictable communication timing or interoperability.
Understanding Industrial Ethernet
Industrial Ethernet supports communication between different types of industrial equipment and applications. Common industrial communication technologies include:
- EtherNet/IP: Industrial communication technology used for controller, device and automation-system communication.
- PROFINET: Industrial Ethernet communication used in automation and distributed control environments.
- Modbus TCP: Ethernet-based communication commonly used to exchange industrial device data.
- OPC UA: A platform-independent communication framework supporting structured information exchange between industrial applications.
Before connecting devices, verify supported protocols, firmware versions, communication modules, software drivers and gateway capabilities.
Also distinguish between monitoring connections and control communication. A gateway suitable for collecting selected equipment measurements may not be appropriate for a time-sensitive control application.
Time-Sensitive Networking (TSN)
Time-Sensitive Networking (TSN) is a family of IEEE 802.1 Ethernet standards designed to support more predictable and time-coordinated data transmission over Ethernet networks.
Traditional Ethernet networks can carry different types of traffic, but time-sensitive industrial applications may require more controlled communication behaviour. TSN introduces mechanisms that help coordinate when traffic is transmitted and how network resources are managed.
Important TSN capabilities include:
- Time synchronization between participating network devices.
- Scheduled traffic transmission for supported applications.
- Traffic prioritization and shaping.
- Improved coordination of time-sensitive communication.
- Support for integrating different traffic types over compatible Ethernet infrastructure.
For example, an automated production environment may need coordinated communication between controllers, drives and distributed devices. A properly designed TSN-capable network may help support those timing requirements.
However, TSN is not automatically necessary for every industrial facility. Its suitability depends on application requirements, endpoint support, switch capabilities, interoperability and the complete network design.
Learn more through the IEEE 802.1 Time-Sensitive Networking working group.
OPC UA and Industrial System Integration
OPC UA can support structured information exchange between industrial equipment, SCADA applications and higher-level operational systems.
Before implementing an OPC UA connection, confirm that the required information models, security settings, certificates, user permissions and communication paths are correctly configured.
The OPC Foundation security model explains the security capabilities that need to be implemented and configured appropriately.
4. Review Network Infrastructure and Physical Reliability
Advanced industrial networking depends on more than communication protocols. Switches, cabling, connectors, power supplies and environmental conditions all influence network reliability.
Even a correctly configured network can experience recurring interruptions when physical infrastructure is unsuitable for the industrial environment.
Industrial Switches and Network Equipment
Industrial switches should be selected according to the actual network architecture, connected devices, supported protocols and environmental requirements.
Evaluate the following considerations:
- Required port capacity and network speeds.
- Supported industrial networking features.
- VLAN and traffic-management capabilities.
- Redundancy protocols supported by the equipment.
- Power requirements and backup arrangements.
- Operating temperature and environmental ratings.
- Monitoring and configuration-management capabilities.
Industrial Cabling and Connectivity
Network cabling must be appropriate for the installation environment. Industrial facilities may experience vibration, electromagnetic interference, temperature variations and physical exposure that are less common in ordinary office environments.
Review cable condition, connector quality, termination methods, installation distances and cable routing.
Fiber Optic and Copper Infrastructure
Copper Ethernet connections are commonly used for equipment within suitable distances, while fiber optic connections can provide longer-distance communication and electrical isolation between network locations.
The choice depends on distance, equipment interfaces, bandwidth requirements and environmental conditions.
ODVA’s EtherNet/IP Media Planning and Installation Manual provides relevant guidance on industrial media selection and installation.
5. Strengthen OT Cybersecurity and Zero Trust Access
As industrial facilities connect operational technology (OT) with information technology (IT), controlling network access becomes increasingly important.
Operational technology includes the systems responsible for monitoring and controlling physical industrial processes. These environments have different availability, performance and safety requirements from ordinary business IT networks.
A cybersecurity strategy must therefore protect industrial assets without disrupting essential production communication.
Industrial Network Segmentation
Network segmentation separates equipment and applications according to their operational roles and communication requirements.
Instead of allowing every device to communicate freely, facilities can define controlled communication paths between different network zones.
Important segmentation practices include:
- Separating critical control networks from general business networks where appropriate.
- Defining permitted communication between network zones.
- Restricting access to PLCs and engineering workstations.
- Controlling connections between IT and OT environments.
- Monitoring authorized remote-access connections.
- Documenting network exceptions and approved communication requirements.
Zero Trust Security Principles
A Zero Trust approach follows the principle that network location alone should not establish trust. Users, devices and communication requests should receive access according to their identity, permissions and operational requirements.
In industrial environments, this approach can include:
- Verifying the identity of users and authorized devices.
- Applying least-privilege access permissions.
- Restricting engineering and administrative access.
- Using controlled and authenticated remote-access methods.
- Reviewing access permissions periodically.
- Monitoring important configuration and security events.
OT Cybersecurity and System Recovery
Security planning should also include verified backups of controller programs, network configurations and relevant application data.
Updates, firewall changes and new access restrictions must be evaluated before deployment because an unsuitable configuration can interrupt production.
For detailed guidance, consult NIST SP 800-82 Revision 3: Guide to Operational Technology Security.
A VLAN alone is not a complete cybersecurity strategy. Effective protection also requires controlled traffic between networks, access management, secure administration and monitoring.
6. Implement Network Redundancy and High Availability
Network redundancy is an important consideration for industrial environments where communication interruptions can affect production, monitoring or equipment coordination.
A redundant architecture provides an alternative network resource or communication path when a defined component becomes unavailable.
Industrial Network Redundancy Strategies
Depending on the application and equipment capabilities, redundancy may involve:
- Alternative network communication paths.
- Supported industrial Ethernet ring architectures.
- Redundant network links and switching infrastructure.
- Independent power arrangements for critical network equipment.
- Redundant servers for supported supervisory applications.
- Documented recovery and restoration procedures.
High Availability for Industrial Applications
High availability involves more than installing duplicate network equipment. The complete system must be evaluated, including controllers, servers, storage, power, communication paths and application recovery behaviour.
For example, a redundant SCADA server arrangement may provide an alternative supervisory resource. However, the application must support the required failover behaviour, and its communication dependencies must be verified.
Test Network Recovery Behaviour
Redundancy should be tested against realistic failure scenarios.
Testing should establish:
- Which component failures the design is intended to tolerate.
- Whether alternative paths are physically independent.
- How long network communication takes to recover.
- Whether PLC and HMI applications reconnect correctly.
- Whether SCADA data remains accurate after recovery.
- Whether the production process responds as expected.
Rockwell Automation’s Device Level Ring application guidance illustrates how network recovery depends on the selected architecture and configuration.
Important: Network redundancy does not automatically guarantee uninterrupted production. Recovery must be verified across the network and the applications that depend on it.
7. Use Industrial Monitoring and Operational Data
Industrial monitoring helps teams understand network conditions, equipment behaviour and recurring communication problems.
When network information is combined with PLC, HMI and SCADA event records, maintenance teams can investigate issues more effectively and identify patterns that may otherwise remain unnoticed.
Network Monitoring
Monitoring activities may include:
- Switch and network-device availability.
- Communication errors and link changes.
- Network utilization and traffic patterns.
- Device connection status.
- Configuration changes and important events.
- Communication timeouts and application interruptions.
Industrial Condition Monitoring
Connected industrial equipment can generate operational information such as temperature, vibration, operating status and equipment utilization.
Collecting and reviewing this information can help maintenance teams recognize defined abnormal conditions and investigate recurring equipment problems.
However, condition monitoring and predictive maintenance are not interchangeable. Predictive maintenance requires a validated method that relates collected measurements to equipment condition and maintenance decisions.
Connecting Industrial Data with Operational Decisions
Monitoring becomes more useful when each measurement has a defined purpose and an assigned owner.
Facilities should establish:
- Which measurements need to be collected.
- How frequently information should be updated.
- How missing or outdated data is identified.
- Which conditions generate alerts.
- Who investigates and responds to each alert.
- How monitoring results are reviewed over time.
These practices help ensure that monitoring supports actual maintenance and operational decisions rather than simply generating additional data.
8. Evaluate Wireless Networking and Edge Computing
Industrial facilities increasingly use connected devices, mobile equipment and applications that require access to operational information from different locations.
Wireless connectivity and edge computing can support selected industrial applications, but their suitability must be evaluated against the requirements of the production environment.
Industrial Wireless Connectivity
Wi-Fi 6 and other industrial wireless technologies can support applications involving mobile devices, monitoring equipment and connected operational systems.
Wireless connectivity may be useful for:
- Mobile operator terminals.
- Selected industrial monitoring devices.
- Mobile equipment and approved wireless endpoints.
- Access to operational information in designated areas.
- Applications where physical cabling is difficult or impractical.
Before deployment, assess wireless coverage, interference, roaming behaviour, device compatibility, authentication and connection recovery.
Private cellular networks may also be considered for specific mobility or coverage requirements. However, they should only be evaluated when a documented application justifies the additional infrastructure and operational complexity.
Neither Wi-Fi 6 nor private cellular connectivity should automatically be assumed suitable for every time-sensitive control application.
Edge Computing for Industrial Operations
Edge computing moves selected data processing closer to the equipment generating the information.
Instead of sending every measurement to a remote platform for processing, compatible edge systems can perform selected local functions before transmitting relevant information to supervisory or enterprise applications.
Potential applications include:
- Local collection and processing of equipment measurements.
- Buffering data during temporary external connectivity interruptions.
- Filtering and organizing industrial information.
- Supporting local operational dashboards.
- Processing selected monitoring and analytical workloads.
For example, an edge device may collect temperature and vibration measurements from industrial equipment, process the information locally and transmit relevant results to a supervisory platform.
However, edge computing should not be treated as a replacement for PLC control logic or dedicated safety systems. Critical control and safety functions must remain within their appropriately designed and supported architectures.
Connecting Multiple Industrial Locations
Organizations operating multiple facilities may need controlled communication between production locations, central monitoring environments and approved external services.
Network planning should establish which applications require external connectivity, how communication is protected and what local functions remain available when an external connection becomes unavailable.
External network connectivity should support industrial operations without creating unnecessary dependencies for essential local control functions.
9. Plan Network Upgrades and Performance Testing
Industrial network upgrades should follow a documented engineering process. Replacing switches, changing network architecture or introducing new communication technologies without suitable preparation can create additional production risks.
Assess the Existing Network
Begin by reviewing existing network drawings, equipment configurations, controller information, communication requirements and reported performance problems.
Define the Upgrade Requirements
Identify which weaknesses need correction and which improvements are justified by the operational requirements.
Potential upgrade activities may include:
- Replacing unsuitable or unsupported network equipment.
- Correcting cabling and physical infrastructure problems.
- Improving network segmentation and access controls.
- Reviewing industrial protocol compatibility.
- Introducing supported redundancy arrangements.
- Improving monitoring and documentation.
- Updating network architecture for approved future expansion.
Plan Migration and Change Management
Before implementing changes, establish an approved maintenance window, verified configuration backups, responsible personnel and a rollback plan.
Where practical, validate proposed changes in a representative test environment before introducing them into production.
Perform Industrial Network Acceptance Testing
Testing should confirm that the upgraded infrastructure supports the intended equipment and applications.
| Testing Area | Acceptance Evidence |
|---|---|
| Device Connectivity | Required industrial devices communicate correctly. |
| Protocol Compatibility | Supported protocols and applications exchange the intended information. |
| Network Performance | Measured performance meets agreed application requirements. |
| Network Security | Required communication is permitted and unauthorized paths are restricted. |
| Redundancy | Approved failure scenarios produce the expected recovery behaviour. |
| SCADA and HMI | Operator displays, alarms and supervisory communication function correctly. |
| Documentation | Updated network drawings, configurations and test records are available. |
Document outstanding issues, test results, configuration baselines and operational responsibilities before handing over the upgraded system.
Smartopia’s industrial automation services connect networking requirements with PLC, HMI and SCADA project planning, testing and documentation within the agreed project scope.
Plan an Industrial Network Assessment in Toronto and the GTA
Smartopia is based in Mississauga and supports industrial automation projects across Toronto and the Greater Toronto Area.
Improving industrial networking begins with understanding the equipment, communication requirements and operational problems within the facility. A suitable technical review should consider existing network infrastructure, controller configurations, reported communication faults and production constraints.
Before discussing an upgrade, prepare relevant information such as:
- Existing industrial network diagrams.
- PLC, HMI and SCADA equipment details.
- Network switch models and configurations.
- Known communication faults and event records.
- Existing redundancy and cybersecurity arrangements.
- Available maintenance and production windows.
This information helps establish the technical requirements and determine which improvements should be prioritized.
Discuss your industrial networking requirements with Smartopia or call +1 (888) 404-5888.
Frequently Asked Questions
What Is Industrial Networking?
Industrial networking is the communication infrastructure connecting PLCs, HMIs, industrial drives, remote I/O devices and supervisory applications. It allows industrial equipment and control systems to exchange operational information according to their communication and timing requirements.
How Can Industrial Networking Improve Operational Efficiency?
A suitable industrial network can reduce communication-related interruptions, improve access to equipment information and make recurring faults easier to investigate. The actual benefit depends on the original problem, the implemented changes and verified performance.
What Is the Difference Between Industrial Ethernet and Standard Ethernet?
Industrial Ethernet uses Ethernet-based communication within industrial environments, with equipment, protocols and network designs selected to meet operational requirements. Industrial implementations may require specialized hardware, environmental ratings, traffic handling and supported industrial communication protocols.
What Is Time-Sensitive Networking (TSN)?
TSN is a family of IEEE 802.1 standards that introduces mechanisms for time synchronization and more predictable traffic delivery over compatible Ethernet networks. It can support applications requiring coordinated communication, provided the endpoints and network infrastructure support the necessary features.
Is a VLAN Enough to Secure an Industrial Network?
No. VLANs provide logical network separation, but effective OT security also requires controlled communication between network zones, access permissions, secure remote connections, administration and monitoring.
Does Network Redundancy Guarantee Uninterrupted Production?
No. Network redundancy provides alternative resources or communication paths for defined failure scenarios. Actual recovery depends on the network topology, equipment compatibility, power arrangements, configuration and application behaviour. Testing is necessary to verify the result.
Should Industrial Control Use Wired Ethernet or Wi-Fi?
The choice depends on application timing, mobility, environmental conditions and equipment support. Wired Ethernet often suits fixed industrial equipment, while wireless technologies may support selected mobile or monitoring applications. Both require appropriate design and testing.
What Is the Role of Edge Computing in Industrial Networking?
Edge computing processes selected industrial data closer to where it is generated. It can support local monitoring, data collection, buffering and analytics without requiring every operation to depend on an external platform. It does not automatically replace PLC control or dedicated safety systems.
Can an Industrial Network Be Upgraded Without Replacing Every PLC?
Often, suitable existing PLCs can remain in operation while selected switches, cabling, network configurations, access boundaries or supervisory connections are improved. Feasibility depends on device compatibility, support status, application requirements and the available testing and maintenance arrangements.
Is Industrial Network Monitoring the Same as Predictive Maintenance?
No. Network monitoring identifies communication conditions and network events, while predictive maintenance requires validated methods for interpreting equipment data and estimating equipment condition. Collecting operational data alone does not establish predictive capability.



Comments are closed
